DM-6228H Hybrid MDVR

Mobile DVR, 8CH AHD 4in1 or 8CH IP Cam

Hybrid analog+IP Analog IP-Cam 1080p IPC DIDO ONVIF Profile ST NDAA App P2P QR code Push Alarm RTSP 2 way audio UTC Control over Coaxial VGA HDMI Alarm I/O RS-232 RS-485 GPS Google earth SD Card sdk Taiwan SoC 100Taiwan
DM-6012H H.265 MDVR

 Datasheet Download

  Local
  • New Taiwan SoC solution, TAA and NDAA compliant
  • Embedded HMDVRs for all kinds of vehicles, also suitable for safety driving & drive recorder applications
  • 1-Din design
  • Low power consumption
  • Detachable DVR host
  • Up to 8CH IP Cam/AHD/TVI/CVI HDVR with hexaplex operation - simultaneous record, live, playback, backup, control, & remote access
  • Video compression/decompression with configurable quality
  • Max record/playback capabilities: IP CAM: 240/200fps@1080p/720p; Analog: 60fps@8MP-lite, 96fps@5MP-lite, 120fps@4MP-lite, 160fps@3MP-lite, 120fps@1080p, 240/200fps@1080p-lite/720p/960H
  • Max 80Mbps incoming bandwidth for IP CAM
  • Support HDMI/VGA/RCA output
  • 2.5” internal HDDs (>6TB/HDD) or SSD
  • Digital watermark
  • Up to 8 alarm inputs, support car speeding pulse input with configurable parameters or GPS Data
  • Ethernet and Optional 3G/4G/5G/WIFI support for remote access, with dual streaming support
  • Optional 4 PON for IP Camera support
  • Optional DV-9400 RS232/485 device ; RS232 x 4 (Interchangeable with RS485 x 2)
  • Built in G sensor for alarm of acceleration, brake, left/right turn
  • Built in GPS to support Google Earth and Google Maps
  • Delay Off capability
Remote
  • DVR browser utility
  • Support DDNS Server
  • Push alarm notification for portable device
  • Two-way audio capabilities
  • Audio broadcasting
  • Dynamic electronics maps for CMS
  • Remote setup, monitoring, backup, alarm notification, & remote software upgrade
  • iPhone/iPad/Mac/Android/MS-Windows remote software
  • 1 I.E./Firefox/Chrome/App for multiple DVRs
  • Configurable HTTP/SMTP/FTP/Control/Data port
  • Support Google Earth and Google Map
  • Support UPnP, P2P and QR code (Optional)
  • MS-Windows/iOS/Android SDK for the integration with different applications
